Best DEWALT DWS779 LED light Upgrade to mod your saw to a DWS780..

Vote
72 72 views
1y Mar 26, 2021
G

This mod is simple and non-invasive to your saw. A bright LED array without cutting any internal wires to your saw. Just like the DWS780, only cheaper. Best of all, it remains integrated in the exact physical placement as the DWS780. All without tampering with the saw's wiring.

Takes only 30 minutes to complete and provides a true shadow-line to your work piece.
Better than relying on lasers as they typically lose alignment.

Shadow-lines never needs to be aligned. On/Off switch is literally at your finger tips.

I recommend using the components lists below. It's cheap and effective. Feel free to
even stack up two to three circuit boards in a step-like formation for a stronger array of brighter light output.

Have any questions? Feel free to ask in the comments below and I'll be sure to answer
as best I can.

Components can be purchased here:
LED circuit array: https://amzn.to/3fj4WhS
Raspberry Pi Power supply with switch: https://amzn.to/31onmFK

Don't forget to unplug the unit before starting this project and leave it unplugged throughout the duration of the mod until it is complete and you are confident it is installed secure, safe, and ready for use. Wear goggle and respect the laws of electricity!

Because this mod is non-invasive, the mod can be removed or upgraded further.

Disclaimer:
I take no responsibility in your decisions or actions. This video is only for informative purposes. If you choose to perform this modification, you are doing it at your own risk. You need to be comfortable handling electricity, power tools, and modifying your tools. The product(s) warranty may or may not be voided from this mod. You are responsible for your own actions.
